SPECTIVE CONNECT

The operator information App SPECTIVE CONNECT

SPECTIVE CONNECT is the logical extension of the SPECTIVE operating concept. All important information is transmitted to the operator's smartphone. Irrespective of whether the operator is in an excavator or wheel loader or somewhere else nearby, they always have all relevant information on the status of the machine at their disposal.* Apart from relevant data such as fuel consumption, current production output, diesel and urea filling levels, fault messages are also displayed. Work does not need to be interrupted to view the status. The option for preparing clearly arranged reports creates additional transparency for the operating company.

Features SPECTIVE CONNECT
Dashboard – all current data at your fingertips

A non-verbal display provides a clearly arranged presentation of all current information on the crushing plant relevant to the operator, who always has a view of the current status of the machine.

Fault elimination aids - always with best possible support

All active faults displayed on the SPECTIVE touch panel on the machine are displayed at the same time via SPECTIVE CONNECT on the smartphone. The operator finds out what has to be done and is also supported in a targeted manner with fault elimination aids. Depending on the type of fault, they can decide whether it is necessary to leave the excavator or wheel loader. In each case, they can use the fault elimination aids to intervene directly at the point of occurrence and eliminate the fault. This effectively reduces downtimes and increases productivity!

Stockpile monitoring - for even higher productivity

Stockpile monitoring allows SPECTIVE CONNECT to display the current status of material stockpiles. When a certain value is reached (e.g. 90%), the App informs you that the stockpile soon has to be cleared. In the case of plant trains, in particular, where the excavator driver does not have a view of all stockpiles and the wheel loader driver has other tasks to complete, this can considerably facilitate the work. This can help to prevent shutdowns and increase productivity.

Camera live images - everything at a glance

If the machine is equipped with the optionally available camera system, live video images from the camera can display the crusher inlet and the feeding area in SPECTIVE CONNECT (with the MR 130(i) PRO, in addition, the transfer point of the material return to the secondary screening unit). For a view of what is happening while comfortably seated at the wheel loader or excavator.

> Presentation of several cameras in the split-screen

> Switch to the vertical display (landscape) possible

Reporting - meaningful and informative

The reporting system provides operators of screening and crushing plants with meaningful findings about their plants. The status of the machines can be viewed, but optimisation potential can also be deduced.

Smart Job Configurator

The Smart Job Configurator tool helps the operator select and enter the correct machine settings – irrespective of the application. This saves time, provides safety and guarantees a high-quality final product with the lowest possible wear and fuel consumption.

Performance Assistant

The Performance Assistant supports operators even more with their daily work. The system monitors different values in the crushing process and can use them to make improvement suggestions. The operator therefore receives a push notification if the current production output no longer corresponds to the output calculated in the Smart Job Configurator.

Tool Management

Tool Management permits documentation of the plant crushing tools and their wear in SPECTIVE CONNECT. This is carried out with the Tool determination and Tool logbook functions.

Good to know - All advantages at a glance
Operator information App
  • All relevant data at a glance
  • Overview of all plants in the train
  • The operator can remain in the excavator/wheel loader
  • No interruption to the work process
  • Increased operational and work safety
Show more Show Less
Prior to initial start

During the initial connection, a QR code appears in the SPECTIVE plant display at the push of a button. Scan this code with the smartphone and the plant is already connected with the SPECTIVE CONNECT App. The connection is always set up automatically if you are in the vicinity of the machine. Even plants without a touch display can be connected easily with SPECTIVE CONNECT.

Fast setup thanks to Quickstart

Even without SPECTIVE CONNECT, the Smart Job Configurator can be used on the touch panel. The Quick start function guides the operator step-by-step through the machine configuration. The setting options are the same as with the App, which further speeds up the set-up process.

Displaying several machines in SPECTIVE CONNECT

On the touch panel, a plant train can be created in the SPECTIVE CONNECT menu. The operator can then connect with a (master) plant in SPECTIVE CONNECT and view several machines at the same time, or switch between them. Up-to-date data can therefore be displayed for every plant.

Irrespective of which plant is currently shown in the dashboard, notifications and messages from all plants are actively signalled.

Is your plant ready for SPECTIVE CONNECT?

If your plant is equipped with the SPECTIVE CONNECT option, then simply download the app for your smartphone and get started!

1. Select the WiFi symbol on the SPECTIVE start screen.
2. Scan the QR code and you are connected with the plant immediately.

Following this, the connection is always established when you are in the vicinity of the machine.

SPECTIVE CONNECT simplifies the interaction between operator and mobile crushing plant.

SPECTIVE CONNECT is the logical extension of the SPECTIVE operating concept. All important information on the crushing plant is transmitted to the operator's smartphone.

The Smart Job Configurator tool helps the operator select and enter the correct machine settings – irrespective of the application.

Please feel free to contact us!
Downloads
English (PDF 1 MB)
English (PDF 2 MB)
English (PDF 1 MB)
Frequently asked questions (FAQ)

Yes SPECTIVE Connect builds up its own WLAN. The WLAN is secure and can only be accessed with the corresponding password.

The distance from which SPECTIVE CONNECT can receive data from the plant depends heavily on ambient conditions.

A free view without obstacles results in a longer range. The aim of SPECTIVE CONNECT is to transfer the operating concept with all relevant information on the plant to the operator in the excavator and not to transmit data over a range as far as possible.

As a guideline, however, in an area of 50-80 m around the crushing plant a good reception can be expected; even further depending on the situation.

Specialized knowledge: If the operator leaves the reception area with SPECTIVE CONNECT and then returns, he connects again automatically with the plant.

An overview showing all machines for which SPECTIVE CONNECT is available can be found at the bottom of the page under "Downloads"

SPECTIVE CONNECT can be retrofitted on all plants for which it is also available in series production. As is the case usually with retrofittable options, assembly instructions will also be delivered.

An overview showing all machines for which SPECTIVE CONNECT is available can be found at the bottom of the page under "Downloads"

Yes it will be possible to connect with a plant train.

Yes, that is possible. If too many devices are connected, however, malfunctions are possible as with every WLAN. Normally a maximum of 3 persons are in the vicinity of a plant. They can connect to the plant at the same time without any problems.

Yes, SPECTIVE CONNECT also has offline functions free of charge. They can also be used without hardware.

Simply download the App from the App Store or Google Play and try it out.

On the contrary: Thanks to SPECTIVE CONNECT, the operator does not need to climb out of the excavator or wheel loader as much as before to obtain information from the plant. As a result, the work process is interrupted less frequently and the plant performance and efficiency are increased.

The operator enters the danger area around the plant less than usual and is not exposed as much to environmental influences such as noise, dust, heat, cold and dampness. This increases comfort and work safety.

Plant performance, consumption and plant utilisation are made available in a transparent report. Apart from the basic documentation, this also provides an option for analysing the production process.

Furthermore, SPECTIVE CONNECT supports troubleshooting in a targeted manner and contributes to the reduction in downtimes if a fault should happen to occur on a machine.

As the WLAN of the plant has no connection to the Internet, a prompt usually appears on the smartphone asking whether mobile data is to be used in addition to the WLAN. This allows the operator to use the Internet and SPECTIVE CONNECT simultaneously.

SPECTIVE CONNECT has no effect at all on your data volume because the App still receives all data via the WLAN of the plant.

Important: The function was deactivated often in the past when users, e.g. save data in the local WLAN and want to avoid surfing accidentally in the Internet via the mobile data connection.

All belt scales and their individual results are listed.

The App can be used to create recipes, but even without the App the Smart Job Configurator provides rapid entry for convenient setting of the machine.

No, they still have to be entered manually.

No, the original settings are retained until they are changed manually.

The recipes can be exported from the App as a PDF and saved.

* It is possible that the App or individual features of it are not yet available in every country.
