AB 500 Extending screed

TV, TP1, TP2, TP2 Plus

2.55 m - 8.75 m

2.55

Extending screed of the Dash 5 generation

The latest generation of the AB 500 makes a strong team together with the SUPER 1900-5(i) and SUPER 2100-5(i) Dash 5 pavers. With its infinitely adjustable single-tube telescoping system, this screed covers a virtually unlimited spectrum of applications with paving widths ranging from 2.55 meters (8.37 ft) to 5 meters (16.4 ft), and even to 8.75 meters (28.7 ft) with bolt-on extensions.

Show less

Technical specifications

Basic width

Hydraulically adjustable

Minimum paving width

Maximum paving width

Bolt-on extensions

Basic width: 2.55 m

Hydraulically adjustable: 2.55 m to 5.00 m

Minimum paving width: 2.55 m

Maximum paving width: 8.75 m

Bolt-on extensions

Length
37.5 cm
75 cm
125 cm

Version

Crown adjustment

Height adjustment, extending units

Slope, extending units (max.)

Version: hydraulic

Crown adjustment: -2.5 % to 5 %

Height adjustment, extending units: -20 mm to 25 mm

Slope, extending units (max.): 4 %

Compacting systems

Vibrators (V)

Version

Frequency (max.)

Tamper (T)

Speed (max.)

Stroke, standard (TV, TP1, TP2)

Stroke, optional hydraulic (TV, TP1, TP2)

Pressure bars (P)

Pressure bar drive (P)

Pressure bar pulse frequency (P) (max.)

Hydraulic oil pressure (max.)

Compacting systems: TV, TP1, TP2, TP2 Plus

Version: eccentric vibrators

Frequency (max.): 50 Hz

Speed (max.): 1,800 rpm

Stroke, standard (TV, TP1, TP2): 4 mm

Stroke, optional hydraulic (TV, TP1, TP2): 2 mm, 4 mm

Stroke, optional hydraulic (TV, TP1, TP2): 4 mm, 8 mm

Pressure bar drive (P): pulsed hydraulic

Pressure bar pulse frequency (P) (max.): 68 Hz

Hydraulic oil pressure (max.): 120 bar

Heating rods

Output generation

Optional screed heating

Control

Heating rods: on screed plates and in tamper bars

Output generation: three-phase AC generator

Optional screed heating: function monitoring of each individual heating rod

Control: fully automatic, thermostat-controlled

Width (without end gate)

Basic screed weight

Depth (in transport position)

Width (without end gate): 2.55 m

Basic screed weight

Screed	Weight
TV	3,300 kg
TP1	3,700 kg
TP2	4,000 kg
TP2 Plus	4,250 kg

Depth (in transport position)

Screed	Depth
AB 500 TV	1.29 m
AB 500 TP	1.42 m
