Pneumatic-tire rollers in the 6–10 t weight class HP 100i

HP 100i Pneumatic-tire rollers in the 6–10 t weight class

67.9 in

12,987 lbs

EU Stage IIIB / EPA Tier 4

  • Electronic machine management Hammtronic
  • Simple, intuitive and language-neutral control
  • Excellent view of tires, machine and construction site
  • High compaction and surface quality due to even weight distribution and tire overlap of the front and rear wheel pairs
  • Seat-operating unit can be moved and rotated
Show less

Three-point articulation

Three-point articulation is different to conventional joints due to its geometric arrangement and connection of the three individual joints and one additional connecting link between the two conventional upper joints. This allows optimum steering, excellent driving safety and maximum driving comfort.

Learn more

HAMMTRONIC

HAMMTRONIC is an electronic machine management system that monitors and controls all key machine functions, consequently increasing safety, economy and fuel savings. The opportunities offered by HAMMTRONIC include, for instance, automatic adjustment of the diesel engine speed to meet the power requirements of the individual drives. Moreover, HAMMTRONIC controls start-up and braking, and distributes the drive torques across the drum axis and back wheels in line with current operating data. HAMMTRONIC also controls the hydrostatic vibration drive and the various steering programs (for DV+ series only), guaranteeing even, smooth movement of both drums.

Learn more

Technical specifications

Series
Name
Description
Exhaust emissions category
Series
Series
HP
Name
HP 100i
Description
Pneumatic-tire rollers in the 6–10 t weight class
Exhaust emissions category
EU Stage IIIB / EPA Tier 4
Series
H300
Operating weight with ROPS
Empty weight without cab, without ROPS
Operating weight with cab
Axle load, rear
Axle load, front
Wheel load per tire, rear
Wheel load per tire, front
Operating weight with ROPS
12,613 lbs
Empty weight without cab, without ROPS
11,907 lbs
Operating weight with cab
12,987 lbs
Axle load, rear
6,064 lbs
Axle load, front
6,924 lbs
Wheel load per tire, rear
1,517 lbs
Wheel load per tire, front
1,385 lbs
Total length
Total width with cab
Maximum working width
Total height with cab
Center distance
Ground clearance, center
Turning radius, inside
Total height with ROPS
Total length
180.7 in
Total width with cab
71 in
Maximum working width
67.9 in
Total height with cab
113.1 in
Center distance
131.5 in
Ground clearance, center
13.4 in
Turning radius, inside
163 in
Total height with ROPS
116.2 in
Number of tires, rear
Number of tires, front
Tire size, rear
Tire size, front
Width over tires, rear
Width over tires, front
Number of tires, rear
4
Number of tires, front
5
Tire size, rear
7.50-15
Tire size, front
7.50-15
Width over tires, rear
53.1 in
Width over tires, front
67.9 in
Manufacturer
Model
Cylinders, quantity
Exhaust emission standard
Exhaust gas after-treatment
Power ISO 14396, rpm
Power ISO 14396, HP
Power ISO 14396, kW
Power SAE J1349, rpm
Power SAE J1349, HP
Power SAE J1349, kW
Manufacturer
DEUTZ
Model
TCD 2.9 L4
Cylinders, quantity
4
Exhaust emission standard
EU Stage IIIB / EPA Tier 4
Exhaust gas after-treatment
DOC
Power ISO 14396, rpm
2,200 rpm
Power ISO 14396, HP
75.3 HP
Power ISO 14396, kW
55.4 kW
Power SAE J1349, rpm
2,200 rpm
Power SAE J1349, HP
74.2 hp
Power SAE J1349, kW
55.4 kW
Speed, infinitely variable
Speed, infinitely variable
0,0-12,4
Steering, type
Water sprinkling, type
Steering, type
Articulated steering
Water sprinkling, type
Pressure
Water sprinkling, type
Water sprinkling, type
Pressure
Fuel tank, capacity
Water tank, capacity
Fuel tank, capacity
31.7 gal
Water tank, capacity
184.9 gal

Equipment

  • 12 V power socket
  • ROPS, rigid
  • Central water outlet
  • Water tank front and rear, can be filled from both sides
  • Vibration-insulated driver's platform
  • Speed preselect
  • Driver’s platform with access from both sides
  • ECO mode
  • Dashboard tiltable
  • Dashboard with displays, indicator lights and switches
  • Two large exterior rear-view mirrors
Show less

Optional equipment

  • Scraper made from brushes, folding
  • Battery isolation switch
  • Tire lighting, LED
  • Rotating beacon
  • Working spotlights
  • Telematics system
  • Back-up alarm
  • Camera system
  • Automatic engine stop
  • Speedometer
  • Protective roof
  • Fire extinguisher
  • Heating and air-conditioning system
  • ROPS cab with non-split doors (FOPS, level I)
  • Version with water sprinkling
Show less
Show less
HAMM|10019367|10041448
HAMM|10019362|10041443
HAMM|10019365|10041446
HAMM|10019364|10041445
HAMM|10019366|10041447
HAMM|10019363|10041444
Downloads
English (US) (1.0 MB) Albanian (AL) (1.0 MB)Bulgarian (BG) (1.1 MB)Chinese (CN) (1.1 MB)Chinese (TW) (1.1 MB)Czech (CZ) (1.0 MB)Danish (DK) (1.0 MB)Dutch (NL) (1.0 MB)English (GB) (1.0 MB)Estonian (EE) (1.0 MB)Finnish (FI) (1.0 MB)French (FR) (1.0 MB)German (DE) (1.0 MB)Hungarian (HU) (1.0 MB)Italian (IT) (1.0 MB)Japanese (JP) (1.1 MB)Kazakh (KZ) (1.1 MB)Latvian (LV) (1.0 MB)Lithuanian (LT) (1.0 MB)Norwegian Bokmål (NO) (1.0 MB)Polish (PL) (1.0 MB)Portuguese (BR) (1.0 MB)Romanian (RO) (1.0 MB)Russian (RU) (1.1 MB)Serbian (CS) (1.0 MB)Slovak (SK) (1.0 MB)Spanish (ES) (1.0 MB)Swedish (SE) (1.0 MB)Turkish (TR) (1.0 MB)Ukrainian (UA) (1.1 MB)
English (US) (22.5 MB) English (GB) (19.3 MB)French (FR) (19.3 MB)German (DE) (19.3 MB)Portuguese (BR) (26.7 MB)Spanish (ES) (19.3 MB)
Contact us for quotes and prices!
News & Job reports

With the HP 100i pneumatic-tire roller, HAMM is presenting a new machine that is ideally suited to chipseal. To suit the application, the HP 100i is offered with 13,227 lbs (6 t), 17,637 lbs (8 t) or 22,046 lbs (10 t) operating weights.

HP 100i pneumatic-tire roller

HAMM is presenting new compactors, tandem rollers, pivot-steered tandem rollers, electrified tandem rollers, pneumatic-tire rollers and trench rollers at Conexpo/CON-AGG 2023. Also new in the range: Digital solutions for compaction documentation and analysis.

HAMM at Conexpo
Continue reading

All details, illustrations and texts are non-binding and may include special equipment. We reserve the right to make technical changes without prior notice. Performance data are dependent upon actual operational conditions.
