Tracked paver Highway Class SUPER 2000-3i

SUPER 2000-3i Tracked paver Highway Class

3

m

8.6

m

1,400

t/h

The versatile Highway Class tracked paver – a true SUPER paver

With the SUPER 2000-3i, VÖGELE has developed an entirely new paver for the North American market. The tracked paver is designed primarily for use in highway construction and on major infrastructure projects on which the key focus is on performance and productivity. With a powerful 6-cylinder engine and high-performance hydraulic drives, the paver is ideally equipped for such jobs.

Show less
The highlights of the SUPER 2000-3i
Range of Applications
Engine
VÖGELE EcoPlus
Drive concept
Feed with mix
Operating system
Maintenance-free paver
Extending screed

Niveltronic Plus

The automatic levelling system Niveltronic Plus is an in-house development of JOSEPH VÖGELE AG and based on many years of experience in grade and slope control technology. Easy operation, precision and reliability are its hallmarks for perfect mastery of all grade and slope control jobs.

More

Technical specifications

Engine
Version
Manufacturer
Type
Exhaust emissions standard
Exhaust emissions after-treatment
Nominal output
ECO mode output
Fuel tank
Version
liquid-cooled 6-cylinder diesel engine
Manufacturer
Cummins
Type
QSB 6.7 - C250
Exhaust emissions standard
European exhaust emissions standard 4, US standard EPA Tier 4f
Exhaust emissions after-treatment
DOC, SCR
Nominal output
186 kW / 2,000 U/min
ECO mode output
167 kW / 1,700 U/min
Fuel tank
320 l
Undercarriage
Version
Ground contact
Traction drive crawler tracks
Track tension adjuster
Speeds
Pave speed (up to)
Travel speed (up to)
Lubrication of track rollers
Version
provided with rubber pads
Ground contact
2,994 mm x 457 mm
Traction drive crawler tracks
separate hydraulic drives with electronic control
Track tension adjuster
hydraulic
Pave speed (up to)
76 m/min
Travel speed (up to)
12 km/h
Lubrication of track rollers
lifetime
Hopper capacity
Width
Feed height (bottom of material hopper)
Push-rollers
Standard
Positions
Hopper capacity
15 t
Width
3,420 mm
Feed height (bottom of material hopper)
595 mm
Standard
oscillating
Positions
can be adjusted in a forward direction by 75 mm or 150 mm
Conveyors
Number
Version
Drive
Speed (up to)
Augers
Number
Version
Diameter
Drive
Rpm (up to)
Height
Standard height
Lubrication
Number
2
Version
with replaceable feeder bars, direction of conveyor temporarily reversible
Drive
separate hydraulic drives, proportional control
Speed (up to)
60 m/min
Number
2
Version
with replaceable auger blades, auger rotation reversible
Diameter
400 mm
Drive
separate hydraulic drives, proportional control
Rpm (up to)
130 U/min
Height
infinitely variable
Standard height
hydraulically adjustable by 15 cm
Lubrication
centralized lubrication system, electrically-driven grease pump
Screed
Layer thickness (up to)
Heating
Power Supply
Screed
Type Basic width Maximum width Compacting systems
VF 600 3.05 m 7.75 m V
VR 600 3.05 m 8.6 m V
AB 600 3 m 8.5 m TV
Layer thickness (up to)
30 cm
Heating
electric, thermostat-controlled
Power Supply
Three-phase AC generator
Operating weight
Length
Operating weight
Screed Total weight
VR 600 22,300 kg
VF 600 21,900 kg
AB 600 TV 22,450 kg
Length
Screed Total length
VR 600 6.87 m
VF 600 6.56 m
AB 600 TV 6.63 m

All details, illustrations and texts are non-binding and may include special equipment. We reserve the right to make technical changes without prior notice. Performance data are dependent upon actual operational conditions.
